输入输出Input/Output:                           2 x 6 ways(XLR)

MAX输出Max output level:                   +9dBu (600 Ω loading)

频响Frequency response:                   20Hz-20kHz(-0.3dB)

动态范围Dynamic range:                     >110dB(20Hz-20kHz)

总谐波失真THD+N:                                <0.05%(20Hz-20kHz 0dBu)

MAX延时Max delay :                               8ms(step pitch:15μs)

参量均衡数目PEQ :                                 10 bands/each channel output

Q值参数Filter Q value:                           0.2-25 adjustable  step pitch: 0.1 adjustable

 压限阀值Limiter threshold value:       -50dBu ~ +9dBu

取样频率Sampling rate :                        96kHz    Phase :180°

显示屏LCD Display:                                2 X 16 Pix (白色背光)

备注： SAE保留对以上参数的解释权，参数有所变动恕不另行通告，具体参数以产品说明书为准。
